ModuleBox V4 Smart Aircooled Container

In Stock


Please download our ModuleBox V4 brochure in the “Downloads” tab for detailed information and specifications.

30 day production time plus ocean freight transit. Will provide reduced invoice for customs clearance. Door-to-Door shipping available (ranges between $4,000 USD – $12,000 USD depending on model selection and final destination of delivery).

  • Size: 20 Footer
  • Certification: 20HC-cUL
  • Quantity of units: 210
  • Phone App Management: Normal


  • Maximum rated load:900kw/h
  • Fuse protection:125A*20 sets

Three-phase equilibrium Each PDU is a sine wave with the same frequency, amplitude and phase difference of 120 degrees.
Current protection: When the current flowing through the protected parts exceeds a pre-set value, the protection device starts and uses the time limit to ensure the selectivity of the action, so that the circuit breaker trips or gives an alarm signal.

ModuleBox V4 Smart Aircooled Container


✔ Loss of voltage protection: When the power is suddenly cut off due to some external reasons, the power can be cut off automatically;

✔ Phase loss protection: When one phase of the three-phase power supply is disconnected, the three-phase equipment will reduce the output power and cannot work normally, or cause accidents. Therefore, some important equipment need to add phase loss protection device.

✔ Undervoltage protection: refers to the action of the protection appliance when the line voltage is reduced to the critical level, and its task is mainly to prevent the equipment from burning up due to overload.

✔ Automatic reclosing switch: It is a device that automatically re-closes the circuit breaker after it has been separated due to a fault, using a mechanical device or relay automatic device.

ModuleBox V4 Smart Aircooled Container

Remote System

✔ Global remote control, custom on/off schedule.
✔ Custom socket power usage record inquiry.
✔ Overall safety certification by China Classification Society.
✔ Overall CE certification/cUL safety certification.
✔ The power supply network is isolated from the miner network, eliminating background fee collection.


There are no reviews yet.

Be the first to review “ModuleBox V4 Smart Aircooled Container”

Your email address will not be published. Required fields are marked *

Item Module Box V4
inner size (mm) 11000mm x 2100mm x 2860mm
outside size (mm) 12192mm x 2438mm x 2896mm
capacity 210 / 420 sets S19 pro
Standard cULus / ETL
Operating power (kw) 540kw~830kw
Voltage/frequency 350V~480V AC 50~60Hz
master switch(A) 1260
Shelves 1100*400mm, 6 floors
switch (A) 16AC 420 pieces
Water curtain 16-32 pieces
Cold and hot isolation plate 9-18 pieces
